Liquid bitumen CUTBACK

Cutback bitumen

Cutback bitumen means one section or cut return back. It is liquid and when you take the hydrocarbon from the bitumen it will get soft or hard so by adding solvent to the bitumen will convert to liquid form but under special specification of condition. Sometimes you need to quickly get cure and dry the solvent should be choose accordingly. There is different grade of cutback called Slow Curing, Medium Curing and Rapid Curing.

Cutback bitumen MC 30

In many places, cutback asphalt use is restricted to patching materials for use in cold weather cutback MC-30 is medium curing (MC) cut-back asphalt consisting of penetration grade asphalt cement and diluent or cutter of medium volatility. The diluent temporarily reduces the viscosity of the asphalt cement for ease of handling and application. After application the diluent evaporates, leaving asphalt cement to perform its function Petrochemical Trade Cutback MC-30 conforms to the specifications of ASTM D2127 (Medium-Curing Asphalt) or AASHTO M82The major use for Petrochemical Trade Cutback MC-30 is in the road maintenance industry where it is used as a prime coat of the base course prior to placing of the bituminous surface course. Its purpose is to bind the granular material of the base course to the asphalt layer. Usual application is by spray using a distributor.

Properties	Min	Max	Test Method
Kinemalic 1 viscosity at 60°C, eSt	30	60	ASTM D2170
Flash Point (Tag Open-Cup),°C	38	–	ASTM D1310
Distillate test 2 :
Distillate, percent by Volume of total 360°C
To 190°C	–	15	ASTM D402
To 225°C	20	60	ASTM D402
To 260°C	50	90	ASTM D402
To 316°C	80	90	ASTM D402
Residue from distillation to 360°C:
Test on residue from distillation Penetration at 25°C,100g, 5 sec.	50	–
Ductility 3 at 25°C, cm	120	250	ASTM D402 / ASTM D113
Solubility in trichloroethylene, percent mass	100	–	ASTM D402 / ASTM D2024
Water, percent volume	–	0.2	ASTM D95

Cutback bitumen MC 70

It is medium curing (MC) cut-back asphalt consisting of penetration grade asphalt cement and diluent or cutter of medium volatility. The diluent temporarily reduces the viscosity of the asphalt cement for ease of handling and application. After application the diluent evaporates, leaving asphalt cement to perform its function.Petrochemical Trade MC 70 conforms to the specifications of ASTM D2127 (Medium-Curing Asphalt) or AASHTO M82a) Roofing – As a waterproofing membrane and as an adhesive to stick chippings onto a flat, horizontal roof to minimize the effects of weathering from the sun.

Properties	Min	Max	Test Method
Kinemalic 1 viscosity at 60°C, eSt	70	140	ASTM D2170
Flash Point (Tag Open-Cup),°C	38	–	ASTM D1310
Distillate test 2 :
Distillate, percent by Volume of total 360°C
To 190°C	–	15	ASTM D402
To 225°C	20	60	ASTM D402
To 260°C	65	90	ASTM D402
To 316°C	55	-s	ASTM D402
Residue from distillation to 360°C:
Test on residue from distillation Penetration at 25°C,100g, 5 sec.	50	–
Ductility 3 at 25°C, cm	120	250	ASTM D402 / ASTM D113
Solubility in trichloroethylene, percent mass	100	–	ASTM D402 / ASTM D2024
Water, percent volume	–	0.2	ASTM D95

Cutback bitumen MC 250

Properties	Min	Max	Test Method
Kinemalic 1 viscosity at 60°C, eSt	250	500	ASTM D2170
Flash Point (Tag Open-Cup),°C	66	–	ASTM D1310
Distillate test 2 :
Distillate, percent by Volume of total 360°C
To 190°C	–	10	ASTM D402
To 225°C	15	55	ASTM D402
To 260°C	60	87	ASTM D402
To 316°C	67	–	ASTM D402
Residue from distillation to 360°C:
Test on residue from distillation Penetration at 25°C,100g, 5 sec.	30	120
Ductility 3 at 25°C, cm	120	250	ASTM D402 / ASTM D113
Solubility in trichloroethylene, percent mass	100	–	ASTM D402 / ASTM D2024
Water, percent volume	–	0.2	ASTM D95

Cutback bitumen MC 800

Cutback MC-800 is a medium curing (MC) cut-back asphalt consisting of penetration grade asphalt cement and diluent or cutter of medium volatility.
The diluent temporarily reduces the viscosity of the asphalt cement for ease of handling and application. After application the diluent evaporates, leaving asphalt cement to perform its function.
Petrochemical Trade Cutback MC-800 conforms to the specifications of ASTM D2127 (Medium-Curing Asphalt) or AASHTO M82a) Roofing – As a waterproofing membrane and as an adhesive to stick chippings onto a flat, horizontal roof to minimize the effects of weathering from the sun.
b) Damp-Proof Courses – Used as damp-proof membranes in concrete floors particularly for small repairs or where extensions are keyed-in to existing structures.

Properties	Min	Max	Test Method
Kinemalic 1 viscosity at 60°C, eSt	800	1600	ASTM D2170
Flash Point (Tag Open-Cup),°C	60	–	ASTM D1310
Distillate test 2 :
Distillate, percent by Volume of total 360°C
To 190°C	–	15	ASTM D402
To 225°C	20	60	ASTM D402
To 260°C	50	90	ASTM D402
To 316°C	80	90	ASTM D402
Residue from distillation to 360°C:
Test on residue from distillation Penetration at 25°C,100g, 5 sec.	50	–
Ductility 3 at 25°C, cm	120	250	ASTM D402 / ASTM D113
Solubility in trichloroethylene, percent mass	100	–	ASTM D402 / ASTM D2024
Water, percent volume	–	0.2	ASTM D95

Cutback bitumen MC 3000

Properties	Min	Max	Test Method
Kinemalic 1 viscosity at 60°C, eSt	3000	6000	ASTM D2170
Flash Point (Tag Open-Cup),°C	66	–	ASTM D1310
Distillate test 2 :
Distillate, percent by Volume of total 360°C
To 190°C	–	–	ASTM D402
To 225°C	–	–	ASTM D402
To 260°C	–	15	ASTM D402
To 316°C	80	–	ASTM D402
Residue from distillation to 360°C:
Test on residue from distillation Penetration at 25°C,100g, 5 sec.	80	–
Ductility 3 at 25°C, cm	120	250	ASTM D402 / ASTM D113
Solubility in trichloroethylene, percent mass	100	–	ASTM D402 / ASTM D2024
Water, percent volume	–	0.2	ASTM D95

Cutback bitumen RC 30

Bitumen RC30 is dissolved of bitumen in solvents of kerosene. In many countries kerosene and other volatile petroleum derived products are added as a cutter or cutback agent to bitumen to reduce (or cutback) the viscosity of the bitumen. The mixture obtained may be called cutback bitumen.

The reduction in viscosity of the bitumen RC 30 aids the construction of seal coats in road pavements as the softened mixture wets the chips more easily. The cutback agent evaporates from the seal coat, the cutback agent becoming a negligible component of the seal coat a few months after application. If significant amounts of the cutback agent remain in the seal coat an unwanted long term softening effect may result.

Properties	Min	Max	Test Method
Kinemalic 1 viscosity at 60°C, eSt	30	60	ASTM D2170
Flash Point (Tag Open-Cup),°C	–	–	ASTM D1310
Distillate test 2 :
Distillate, percent by Volume of total 360°C
To 190°C	15	–	ASTM D402
To 225°C	55	–	ASTM D402
To 260°C	75	–	ASTM D402
To 316°C	90	–	ASTM D402
Residue from distillation to 360°C:
Test on residue from distillation Penetration at 25°C,100g, 5 sec.	80	120
Ductility 3 at 25°C, cm	100	–	ASTM D402 / ASTM D113
Solubility in trichloroethylene, percent mass	100	–	ASTM D402 / ASTM D2024
Water, percent volume	–	0.2	ASTM D95

Cutback bitumen RC 70

Properties	Min	Max	Test Method
Kinemalic 1 viscosity at 60°C, eSt	70	140	ASTM D2170
Flash Point (Tag Open-Cup),°C	–	–	ASTM D1310
Distillate test 2 :
Distillate, percent by Volume of total 360°C
To 190°C	10	–	ASTM D402
To 225°C	50	–	ASTM D402
To 260°C	70	–	ASTM D402
To 316°C	85	–	ASTM D402
Residue from distillation to 360°C:
Test on residue from distillation Penetration at 25°C,100g, 5 sec.	55	–
Ductility 3 at 25°C, cm	80	120	ASTM D402 / ASTM D113
Solubility in trichloroethylene, percent mass	100	–	ASTM D402 / ASTM D2024
Water, percent volume	–	0.2	ASTM D95

Cutback bitumen RC 250

Cutback bitumen RC250 is dissolved of bitumen in solvents of kerosene. In many countries kerosene and other volatile petroleum derived products are added as a cutter or cutback agent to bitumen to reduce (or cutback) the viscosity of the bitumen. The mixture obtained may be called cutback bitumen.

Properties	Min	Max	Test Method
Kinemalic 1 viscosity at 60°C, eSt	250	500	ASTM D2170
Flash Point (Tag Open-Cup),°C	27	–	ASTM D1310
Distillate test 2 :
Distillate, percent by Volume of total 360°C
To 190°C	–	–	ASTM D402
To 225°C	35	–	ASTM D402
To 260°C	60	–	ASTM D402
To 316°C	80	–	ASTM D402
Residue from distillation to 360°C:
Test on residue from distillation Penetration at 25°C,100g, 5 sec.	80	120
Ductility 3 at 25°C, cm	100	–	ASTM D402 / ASTM D113
Solubility in trichloroethylene, percent mass	100	–	ASTM D402 / ASTM D2024
Water, percent volume	–	0.2	ASTM D95

Cutback bitumen RC 800

Properties	Min	Max	Test Method
Kinemalic 1 viscosity at 60°C, eSt	800	1600	ASTM D2170
Flash Point (Tag Open-Cup),°C	66	–	ASTM D1310
Distillate test 2 :
Distillate, percent by Volume of total 360°C
To 190°C	–	–	ASTM D402
To 225°C	–	–	ASTM D402
To 260°C	–	35	ASTM D402
To 316°C	45	80	ASTM D402
Residue from distillation to 360°C:
Test on residue from distillation Penetration at 25°C,100g, 5 sec.	50	–
Ductility 3 at 25°C, cm	120	250	ASTM D402 / ASTM D113
Solubility in trichloroethylene, percent mass	100	–	ASTM D402 / ASTM D2024
Water, percent volume	–	0.2	ASTM D95

Cutback bitumen SC 30

PROPERTIES	MIN	MAX	TEST METHOD
KINEMALIC 1 VISCOSITY AT 60°C, EST	30	60	ASTM D2170
FLASH POINT (TAG OPEN-CUP),°C	65	–	ASTM D1310
DISTILLATE TEST 2 :
DISTILLATE, PERCENT BY VOLUME OF TOTAL 360°C	</ td>
TO 190°C	–	–	ASTM D402
TO 225°C	–	–	ASTM D402
TO 260°C	–	–	ASTM D402
TO 316°C	10	30	ASTM D402
RESIDUE FROM DISTILLATION TO 60°C: 250 5000
TEST ON RESIDUE FROM DISTILLATION PENETRATION AT 25°C,100G, 5 SEC.	50	–
DUCTILITY 3 AT 25°C, CM	100	–	ASTM D402 / ASTM D113
SOLUBILITY IN TRICHLOROETHYLENE, PERCENT MASS	100	–	ASTM D402 / ASTM D2024
WATER, PERCENT VOLUME	–	0.2	ASTM D95

Cutback bitumen SC 70

Properties	Min	Max	Test Method
Kinemalic 1 viscosity at 60°C, eSt	70	140	ASTM D2170
Flash Point (Tag Open-Cup),°C	65	–	ASTM D1310
Distillate test 2 :
Distillate, percent by Volume of total 360°C
To 190°C	–	–	ASTM D402
To 225°C	–	–	ASTM D402
To 260°C	–	–	ASTM D402
To 316°C	10	30	ASTM D402
Residue from distillation to 60°C: 400 7000
Test on residue from distillation Penetration at 25°C,100g, 5 sec.	50	–
Ductility 3 at 25°C, cm	100	–	ASTM D402 / ASTM D113
Solubility in trichloroethylene, percent mass	100	–	ASTM D402 / ASTM D2024
Water, percent volume	–	0.2	ASTM D95

Cutback bitumen SC 250

PROPERTIES	MIN	MAX	TEST METHOD
KINEMALIC 1 VISCOSITY AT 60°C, EST	250	500	ASTM D2170
FLASH POINT (TAG OPEN-CUP),°C	80	–	ASTM D1310
DISTILLATE TEST 2 :
DISTILLATE, PERCENT BY VOLUME OF TOTAL 360°C
TO 190°C	–	–	ASTM D402
TO 225°C	–	–	ASTM D402
TO 260°C	–	–	ASTM D402
TO 316°C	4	20	ASTM D402
RESIDUE FROM DISTILLATION TO 60°C: 800 10000
TEST ON RESIDUE FROM DISTILLATION PENETRATION AT 25°C,100G, 5 SEC.	60	–
DUCTILITY 3 AT 25°C, CM	100	–	ASTM D402 / ASTM D113
SOLUBILITY IN TRICHLOROETHYLENE, PERCENT MASS	100	–	ASTM D402 / ASTM D2024
WATER, PERCENT VOLUME	–	0.2	ASTM D95

Cutback bitumen SC 800

PROPERTIES	MIN	MAX	TEST METHOD
KINEMALIC 1 VISCOSITY AT 60°C, EST	250	500	ASTM D2170
FLASH POINT (TAG OPEN-CUP),°C	80	–	ASTM D1310
DISTILLATE TEST 2 :
DISTILLATE, PERCENT BY VOLUME OF TOTAL 360°C
TO 190°C	–	–	ASTM D402
TO 225°C	–	–	ASTM D402
TO 260°C	–	–	ASTM D402
TO 316°C	4	20	ASTM D402
RESIDUE FROM DISTILLATION TO 60°C: 800 10000
TEST ON RESIDUE FROM DISTILLATION PENETRATION AT 25°C,100G, 5 SEC.	60	–
DUCTILITY 3 AT 25°C, CM	100	–	ASTM D402 / ASTM D113
SOLUBILITY IN TRICHLOROETHYLENE, PERCENT MASS	100	–	ASTM D402 / ASTM D2024
WATER, PERCENT VOLUME	–	0.2	ASTM D95
