Types of Bitumen for Paving are essential for achieving optimal performance and durability in road construction. Different bitumen grades, such as 115/15, 9040, and 9525, offer unique properties tailored to specific paving requirements. For example, bitumen grade 115/15 is known for its high resistance to deformation under heavy loads, making it suitable for high-traffic areas. Conversely, grades like 9040 excel in extreme weather conditions, ensuring reliable performance in both hot and cold climates. Specialized types, such as SBS-modified bitumen, provide enhanced elasticity and temperature resistance, which is crucial for pavements subjected to high stress. Selecting the right bitumen grade based on these characteristics ensures that the pavement will withstand various environmental and operational challenges, extending its lifespan and effectiveness.
Bitumen 115/15 is semi solid oxidized grade of pure petroleum bitumen categorized in polycyclic aromatic hydrocarbons and blown bitumen normally used for different purposes in the construction business.
Bitumen 115/15 is air blown asphalt and producing by several method by high temperature and pressure. ATDM has high tech system that change down risk of high pressure and temperature and blowning the asphalt in very short time and by this patent increase asphaltene content quickly by adding additive into asphalt emulsion system under ultrasonic. This type of oxidized bitumen 115/15 has various usages including gel type asphalt for encapsulation of hazardous material and metal surface. Blown asphalt 115/15 is containing: 1. Saturates 2. Aromatic 3. Resin 4. Asphaltens Since containing above material there is special properties of thermoplastic, adhesive, resistance to water and acid, alkalis.
a. Dam proof b. Canal sealer c. Tennis court d. Stockyard e. Paving f. Railroad ballast g. Treatment and road beds h. Leaching bitumen 115/1https://atdmco.com/oxidized-bitumen/oxidized-bitumen-115-15/5 could be classified into so, so gel and gel types by traditional rheology index such as complex flow, asphalt aging index, plastic flow, penetration index, ductility at 25C and correlation of asphaltene aromaticity with H/C ratio. So and so gel type blown asphalt can be used on paving, while gel type asphalt can be used on roofing and metal coating. In industry the majority of gel type of asphalt were produced by air blown in s or so gel type of asphalt.
Oxidized bitumen 115/15 uses in the chemical, fuel, paints, lacquers, varnishes, paper-pulp-board, textile processing, road construction, pavement ,crack seal and repairmen, civil works, roofing, construction industries; sealing and insulating buildings, adhesive, construction materials additive, dust-binding, coating, insulating and impregnating agent, make rubber and plastic products. The oxidized bitumen 115/15 products are for paving, roofing; also used in asphalt based paints for corrosion protection of metals, in lining public works structures, adhesives in electrical laminates, base for synthetic turf; typical uses for oxidized bitumen115/15 include roofing, pipe coating, Portland cement pavement, hydraulic applications, paint manufacturing.
Bonding bitumen compound is availble in grade of 115/15 shape of bitumen blocks and using for joint seal also fixing bitumen roll sheet in case of damag or torn also adhesive of buding material in different layer.
The ATDM is manufacturer of blown asphalt 115/15 in various packing including kraft bag, meltable plastic bag, drum and bulk blown asphalt 115/15 from penetration grade bitumen, which is blown by hot air in a controlled process until the desired specification is reached. The ATDM blown asphalt 115/15 can be supplied in any grade and are designated by two numbers to indicate the softening point and penetration ranges. The blown asphalt grade 115/15 means softening point is 115°c and penetration is 15 desimillimiter is produced in compliance and conformity to ASTM standard and meets the following specification.
ATDM guaranty the quality of blown asphalt 115/15 with arrangement of international inspector to check quality and quantity of the bitumen on each shipment during the loading to vessel and controlling the production by QC team via batch test report before shipping. ATDM guaranty the quality to meet with ASTM/EN 13304:2009.
Bitumen 115/15 | Specification | Test method astm/en13304 |
Specific gravity @ 25/25 cg | 1.01/1.06 | D-70 |
Penetration @ 25 c | 10/20 | D-5 |
Softening point c | 110/120 | D-36 |
Loss on heating(wt) % | 0.2 max | D-6 |
Flash point c | 250 min | D-92 |
Solubility is cs2(wt) % | 99.5 max | D-4 |
Spot test | Negative | A.a.s.h.o.t102 |
Oxidized bitumen 90/15 is semi solid oxidised grade of pure petroleum bitumen categorized in polycyclic aromatic hydrocarbons is normally used for different purposes in the construction business.
Oxidised asphalt 90/15 uses in the chemical, fuel, paints, lacquers, varnishes, paper-pulp-board, textile processing, road construction, pavement ,crack seal and repairmen, civil works, roofing, construction industries; sealing and insulating buildings, adhesive, construction materials additive, dust-binding, coating, insulating and impregnating agent, make rubber and plastic products. The blown asphalt 90/15 products are for paving, roofing; also used in asphalt based paints for corrosion protection of metals, in lining public works structures, adhesives in electrical laminates, base for synthetic turf; typical uses for oxidized asphalt 90/15 include roofing, pipe coating, Portland cement pavement, hydraulic applications, paint manufacturing.
The ATDM is manufacturer of blown asphalt 90/15 in various packing including kraft bag, meltable plastic bag, drum and bulk blown asphalt 90/15 from penetration grade bitumen, which is blown by hot air in a controlled process until the desired specification is reached. The ATDM oxidised bitumen 90/15 can be supplied in any grade and are designated by two numbers to indicate the softening point and penetration ranges. The oxidized asphalt grade 90/15 means softening point is 90°c and penetration is 15 desimillimiter is produced in compliance and conformity to ASTM standard and meets the following specification.
ATDM guaranty the quality of blown bitumen 90/15 with arrangement of international inspector to check quality and quantity of the bitumen on each shipment during the loading to vessel and controlling the production by QC team via batch test report before shipping. ATDM guaranty the quality to meet with ASTM/EN 13304:2009.
Analysis of bitumen 90/15
Bitumen 90/15 | Specification | Test method ASTM/EN13304 |
Specific gravity @ 25/25 cg | 1.01/1.06 | D-70 |
Penetration @ 25 c | 10/20 | D-5 |
Softening point c | 85/95 | D-36 |
Loss on heating(wt) % | 0.2 Max | D-6 |
Flash point c | 250 min | D-92 |
Solubility is CS2(wt) % | 99.5 Max | D-4 |
Spot test | negative | A.A.S.H.O.T102 |
Oxidized bitumen 90/10 is semi solid oxidised grade of pure petroleum bitumen categorized in polycyclic aromatic hydrocarbons is normally used for different purposes in the construction business.
Oxidised asphalt 90/10 uses in the chemical, fuel, paints, lacquers, varnishes, paper-pulp-board, textile processing, road construction, pavement ,crack seal and repairmen, civil works, roofing, construction industries; sealing and insulating buildings, adhesive, construction materials additive, dust-binding, coating, insulating and impregnating agent, make rubber and plastic products. The blown asphalt 90/10 products are for paving, roofing; also used in asphalt based paints for corrosion prote
ction of metals, in lining public works structures, adhesives in electrical laminates, base for synthetic turf; typical uses for oxidized asphalt 90/10 include roofing, pipe coating, Portland cement pavement, hydraulic applications, paint manufacturing.
The ATDM is manufacturer of blown asphalt 90/10 in various packing including kraft bag, meltable plastic bag, drum and bulk blown asphalt 90/10 from penetration grade bitumen, which is blown by hot air in a controlled process until the desired specification is reached. The ATDM oxidised bitumen 90/10 can be supplied in any grade and are designated by two numbers to indicate the softening point and penetration ranges. The oxidized asphalt grade 90/10 means softening point is 90°c and penetration is 10 desimillimiter is produced in compliance and conformity to ASTM standard and meets the following specification.
ATDM guaranty the quality of blown bitumen 90/10 with arrangement of international inspector to check quality and quantity of the bitumen on each shipment during the loading to vessel and controlling the production by QC team via batch test report before shipping. ATDM guaranty the quality to meet with ASTM/EN 13304:2009.
Bitumen 90/10 | Specification | Test method ASTM/EN13304 |
Specific gravity @ 25/25 cg | 1.01/1.06 | D-70 |
Penetration @ 25 c | 5/15 | D-5 |
Softening point c | 85/95 | D-36 |
Loss on heating(wt) % | 0.2 Max | D-6 |
Flash point c | 250 min | D-92 |
Solubility is CS2(wt) % | 99.5 Max | D-4 |
Spot test | negative | A.A.S.H.O.T102 |
Oxidized bitumen 85/25 is semi solid oxidised grade of pure petroleum bitumen categorized in polycyclic aromatic hydrocarbons is normally used for different purposes in the construction business.
Oxidised asphalt 85/25 uses in the chemical, fuel, paints, lacquers, varnishes, paper-pulp-board, textile processing, road construction, pavement ,crack seal and repairmen, civil works, roofing, construction industries; sealing and insulating buildings, adhesive, construction materials additive, dust-binding, coating, insulating and impregnating agent, make rubber and plastic products. The blown asphalt 85/25 products are for paving, roofing; also used in asphalt based paints for corrosion protection of metals, in lining public works structures, adhesives in electrical laminates, base for synthetic turf; typical uses for oxidized asphalt 85/25 include roofing, pipe coating, Portland cement pavement, hydraulic applications, paint manufacturing.
The ATDM is manufacturer of blown asphalt 85/25 in various packing including kraft bag, meltable plastic bag, drum and bulk blown asphalt 85/25 from penetration grade bitumen, which is blown by hot air in a controlled process until the desired specification is reached. The ATDM oxidised bitumen 85/25 can be supplied in any grade and are designated by two numbers to indicate the softening point and penetration ranges. The oxidized asphalt grade 85/25 means softening point is 85°c and penetration is 25 desimillimiter is produced in compliance and conformity to ASTM standard and meets the following specification.
ATDM guaranty the quality of blown bitumen 85/25 with arrangement of international inspector to check quality and quantity of the bitumen on each shipment during the loading to vessel and controlling the production by qc team via batch test report before shipping. ATDM guaranty the quality to meet with ASTM/EN 13304:2009.
Bitumen 85/25 | Specification | Test method ASTM/EN13304 |
Specific gravity @ 25/25 cg | 1.01/1.06 | D-70 |
Penetration @ 25 c | 20/30 | D-5 |
Softening point c | 80/90 | D-36 |
Loss on heating(wt) % | 0.2 Max | D-6 |
Flash point c | 250 min | D-92 |
Solubility is CS2(wt) % | 99.5 Max | D-4 |
Spot test | negative | A.A.S.H.O.T102 |
Blown asphalt 75/25 is semi solid oxidised grade of pure petroleum bitumen categorized in polycyclic aromatic hydrocarbons is normally used for different purposes in the construction business.
Blown asphalt 75/25 uses in the chemical, fuel, paints, lacquers, varnishes, paper-pulp-board, textile processing, road constraction;pavment ,crack seal and repairment, civil works, roofing, construction industries; sealing and insulating buildings, adhesive, construction materials additive, dust-binding, coating, insulating and impregnating agent, make rubber and plastic products. The blown asphalt 75/25 products are for paving,roofing; also used in asphalt based paints for corrosion protection of metals, in lining public works structures, adhesives in electrical laminates, base for synthetic turf; typical uses for oxidized asphalt 75/25 include roofing, pipe coating, portland cement pavement, hydraulic applications, paint manufacturing.
The ATDM is manufacturer of blown asphalt 75/25 in various packing including kraft bag, meltable plastic bag, drum and bulk blown asphalt 75/25 from penetration grade bitumen, which is blown by hot air in a controlled process until the desired specification is reached. The ATDM oxidised bitumen 75/25 can be supplied in any grade and are designated by two numbers to indicate the softening point and penetration ranges. The oxidized asphalt grade 75/25 means softening point is 75°c and penetration is 25 desimillimiter is produced in compliance and conformity to ASTM standard and meets the following specification.
ATDM guaranty the quality of blown bitumen 75/25 with arrangement of international inspector to check quality and quantity of the bitumen on each shipment during the loading to vessel and controlling the production by qc team via batch test report before shipping. ATDM guaranty the quality to meet with ASTM/EN 13304:2009.
Bitumen 75/25 | Specification | Test method ASTM/EN13304 |
Specific gravity @ 25/25 cg | 1.01/1.06 | D-70 |
Penetration @ 25 c | 20/30 | D-5 |
Softening point c | 70/80 | D-36 |
Loss on heating(wt) % | 0.2 Max | D-6 |
Flash point c | 250 min | D-92 |
Solubility is CS2(wt) % | 99.5 Max | D-4 |
Spot test | negative | A.A.S.H.O.T102 |
Blown asphalt 75/35 is semi solid oxidised grade of pure petroleum bitumen categorized in polycyclic aromatic hydrocarbons is normally used for different purposes in the construction business.
Blown asphalt 75/35 uses in the chemical, fuel, paints, lacquers, varnishes, paper-pulp-board, textile processing, road construction, pavement ,crack seal and repairmen, civil works, roofing, construction industries; sealing and insulating buildings, adhesive, construction materials additive, dust-binding, coating, insulating and impregnating agent, make rubber and plastic products. the blown asphalt 75/35 products are for paving,
roofing; also used in asphalt based paints for corrosion protection of metals, in lining public works structures, adhesives in electrical laminates, base for synthetic turf; typical uses for blown asphalt 75/35 include roofing, pipe coating, portland cement pavement, hydraulic applications, paint manufacturing.
The ATDM is manufacturer of blown asphalt 75/35 in various packing including kraft bag, meltable plastic bag, drum and bulk blown asphalt 75/35 from penetration grade bitumen, which is blown by hot air in a controlled process until the desired specification is reached. the ATDM oxidised bitumen 75/35 can be supplied in any grade and are designated by two numbers to indicate the softening point and penetration ranges. The blown asphalt grade 75/35 means softening point is 75°c and penetration is 35 desimillimiter is produced in compliance and conformity to ASTM standard and meets the following specification.
ATDM guaranty the quality of blown asphalt 75/35 with arrangement of international inspector to check quality and quantity of the bitumen on each shipment during the loading to vessel and controlling the production by qc team via batch test report before shipping. ATDM guaranty the quality to meet with ASTM/EN 13304:2009.
Bitumen 75/35 | Specification | Test method ASTM/EN13304 |
Specific gravity @ 25/25 cg | 1.01/1.06 | D-70 |
Penetration @ 25 c | 30/40 | D-5 |
Softening point c | 70/80 | D-36 |
Loss on heating(wt) % | 0.2 Max | D-6 |
Flash point c | 250 min | D-92 |
Solubility is CS2(wt) % | 99.5 Max | D-4 |
Spot test | negative | A.A.S.H.O.T102 |
Oxidized bitumen 85/35 is semi solid oxidised grade of pure petroleum bitumen categorized in polycyclic aromatic hydrocarbons is normally used for different purposes in the construction business.
Oxidised asphalt 85/35 uses in the chemical, fuel, paints, lacquers, varnishes, paper-pulp-board, textile processing, road construction, pavement ,crack seal and repairmen, civil works, roofing, construction industries; sealing and insulating buildings, adhesive, construction materials additive, dust-binding, coating, insulating and impregnating agent, make rubber and plastic products. The blown asphalt 85/35 products are for paving, roofing; also used in asphalt based paints for corrosion protection of metals, in lining public works structures, adhesives in electrical laminates, base for synthetic turf; typical uses for oxidized asphalt 85/35 include roofing, pipe coating, Portland cement pavement, hydraulic applications, paint manufacturing.
The ATDM is manufacturer of blown asphalt 85/35 in various packing including kraft bag, meltable plastic bag, drum and bulk blown asphalt 85/35 from penetration grade bitumen, which is blown by hot air in a controlled process until the desired specification is reached. The ATDM oxidised bitumen 85/35 can be supplied in any grade and are designated by two numbers to indicate the softening point and penetration ranges. The oxidized asphalt grade 85/35 means softening point is 85°c and penetration is 35 desimillimiter is produced in compliance and conformity to ASTM standard and meets the following specification.
ATDM guaranty the quality of blown bitumen 85/35 with arrangement of international inspector to check quality and quantity of the bitumen on each shipment during the loading to vessel and controlling the production by qc team via batch test report before shipping. ATDM guaranty the quality to meet with ASTM/EN 13304:2009.
Bitumen 85/35 | Specification | Test method ASTM/EN13304 |
Specific gravity @ 25/25 cg | 1.01/1.06 | D-70 |
Penetration @ 25 c | 30/40 | D-5 |
Softening point c | 80/90 | D-36 |
Loss on heating(wt) % | 0.2 Max | D-6 |
Flash point c | 250 min | D-92 |
Solubility is CS2(wt) % | 99.5 Max | D-4 |
Spot test | negative | A.A.S.H.O.T102 |
Oxidized bitumen 85/40 is semi solid oxidised grade of pure petroleum bitumen categorized in polycyclic aromatic hydrocarbons is normally used for different purposes in the construction business.
Oxidised asphalt 85/40 uses in the chemical, fuel, paints, lacquers, varnishes, paper-pulp-board, textile processing, road construction, pavement ,crack seal and repairmen, civil works, roofing, construction industries; sealing and insulating buildings, adhesive, construction materials additive, dust-binding, coating, insulating and impregnating agent, make rubber and plastic products. The blown asphalt 85/40 products are for paving, roofing; also used in asphalt based paints for corrosion protection of metals, in lining public works structures, adhesives in electrical laminates, base for synthetic turf; typical uses for oxidized asphalt 85/40 include roofing, pipe coating, Portland cement pavement, hydraulic applications, paint manufacturing.
The ATDM is manufacturer of blown asphalt 85/40 in various packing including kraft bag, meltable plastic bag, drum and bulk blown asphalt 85/40 from penetration grade bitumen, which is blown by hot air in a controlled process until the desired specification is reached. The ATDM oxidised bitumen 85/40 can be supplied in any grade and are designated by two numbers to indicate the softening point and penetration ranges. The oxidized asphalt grade 85/40 means softening point is 85°c and penetration is 40 desimillimiter is produced in compliance and conformity to ASTM standard and meets the following specification.
ATDM guaranty the quality of blown bitumen 85/40 with arrangement of international inspector to check quality and quantity of the bitumen on each shipment during the loading to vessel and controlling the production by QC team via batch test report before shipping. ATDM guaranty the quality to meet with ASTM/EN 13304:2009.
Bitumen 85/40 | Specification | Test method ASTM/EN13304 |
Specific gravity @ 25/25 cg | 1.01/1.06 | D-70 |
Penetration @ 25 c | 35/45 | D-5 |
Softening point c | 80/90 | D-36 |
Loss on heating(wt) % | 0.2 Max | D-6 |
Flash point c | 250 min | D-92 |
Solubility is CS2(wt) % | 99.5 Max | D-4 |
Spot test | negative | A.A.S.H.O.T102 |
Oxidized bitumen 90/40 is semi solid oxidised grade of pure petroleum bitumen categorized in polycyclic aromatic hydrocarbons is normally used for different purposes in the construction business.
Oxidised asphalt 90/40 uses in the chemical, fuel, paints, lacquers, varnishes, paper-pulp-board, textile processing, road construction, pavement ,crack seal and repairmen, civil works, roofing, construction industries; sealing and insulating buildings, adhesive, construction materials additive, dust-binding, coating, insulating and impregnating agent, make rubber
and plastic products. The blown asphalt 90/40 products are for paving, roofing; also used in asphalt based paints for corrosion protection of metals, in lining public works structures, adhesives in electrical laminates, base for synthetic turf; typical uses for oxidized asphalt 90/40 include roofing, pipe coating, Portland cement pavement, hydraulic applications, paint manufacturing.
The ATDM is manufacturer of blown asphalt 90/40 in various packing including kraft bag, meltable plastic bag, drum and bulk blown asphalt 90/40 from penetration grade bitumen, which is blown by hot air in a controlled process until the desired specification is reached. The ATDM oxidised bitumen 90/40 can be supplied in any grade and are designated by two numbers to indicate the softening point and penetration ranges. The oxidized asphalt grade 90/40 means softening point is 90°c and penetration is 40 desimillimiter is produced in compliance and conformity to ASTM standard and meets the following specification.
ATDM guaranty the quality of blown bitumen 90/40 with arrangement of international inspector to check quality and quantity of the bitumen on each shipment during the loading to vessel and controlling the production by QC team via batch test report before shipping. ATDM guaranty the quality to meet with ASTM/EN 13304:2009.
Bitumen 90/40 | Specification | Test method ASTM/EN13304 |
Specific gravity @ 25/25 cg | 1.01/1.06 | D-70 |
Penetration @ 25 c | 35/45 | D-5 |
Softening point c | 85/95 | D-36 |
Loss on heating(wt) % | 0.2 Max | D-6 |
Flash point c | 250 min | D-92 |
Solubility is CS2(wt) % | 99.5 Max | D-4 |
Spot test | negative | A.A.S.H.O.T102 |
Oxidized bitumen 95/25 is semi solid oxidised grade of pure petroleum bitumen categorized in polycyclic aromatic hydrocarbons is normally used for different purposes in the construction business.
Oxidised asphalt 95/25 uses in the chemical, fuel, paints, lacquers, varnishes, paper-pulp-board, textile processing, road construction, pavement ,crack seal and repairmen, civil works, roofing, construction industries; sealing and insulating buildings, adhesive, construction materials additive, dust-binding, coating, insulating and impregnating agent, make rubber and plastic products. The blown asphalt 95/25 products are for paving, roofing; also used in asphalt based paints for corrosion protection of metals, in lining public works structures, adhesives in electrical laminates, base for synthetic turf; typical uses for oxidized asphalt 95/25 include roofing, pipe coating, Portland cement pavement, hydraulic applications, paint manufacturing.
The ATDM is manufacturer of blown asphalt 95/25 in various packing including kraft bag, meltable plastic bag, drum and bulk blown asphalt 95/25 from penetration grade bitumen, which is blown by hot air in a controlled process until the desired specification is reached. The ATDM oxidised bitumen 95/25 can be supplied in any grade and are designated by two numbers to indicate the softening point and penetration ranges. The oxidized asphalt grade 95/25 means softening point is 95°c and penetration is 25 desimillimiter is produced in compliance and conformity to ASTM standard and meets the following specification.
ATDM guaranty the quality of blown bitumen 95/25 with arrangement of international inspector to check quality and quantity of the bitumen on each shipment during the loading to vessel and controlling the production by QC team via batch test report before shipping. ATDM guaranty the quality to meet with ASTM/EN 13304:2009.
Bitumen 95/25 | Specification | Test method ASTM/EN13304 |
Specific gravity @ 25/25 cg | 1.01/1.06 | D-70 |
Penetration @ 25 c | 20/30 | D-5 |
Softening point c | 90/100 | D-36 |
Loss on heating(wt) % | 0.2 Max | D-6 |
Flash point c | 250 min | D-92 |
Solubility is CS2(wt) % | 99.5 Max | D-4 |
Spot test | negative | A.A.S.H.O.T102 |
Oxidized bitumen 105/15 is semi solid oxidised grade of pure petroleum bitumen categorized in polycyclic aromatic hydrocarbons is normally used for different purposes in the construction business.
Oxidised asphalt 105/15 uses in the chemical, fuel, paints, lacquers, varnishes, paper-pulp-board, textile processing, road construction, pavement ,crack seal and repairmen, civil works, roofing, construction industries; sealing and insulating buildings, adhesive, construction materials additive, dust-binding, coating, insulating and impregnating agent, make rubber and plastic products. The blown asphalt 105/15 products are for paving, roofing; also used in asphalt based paints for corrosion protection of metals, in lining public works structures, adhesives in electrical laminates, base for synthetic turf; typical uses for oxidized asphalt 105/15 include roofing, pipe coating, Portland cement pavement, hydraulic applications, paint manufacturing.
The ATDM is manufacturer of blown asphalt 105/15 in various packing including kraft bag, meltable plastic bag, drum and bulk blown asphalt 105/15 from penetration grade bitumen, which is blown by hot air in a controlled process until the desired specification is reached. The ATDM oxidised bitumen 105/15 can be supplied in any grade and are designated by two numbers to indicate the softening point and penetration ranges. The oxidized asphalt grade 105/15 means softening point is 105°c and penetration is 15 desimillimiter is produced in compliance and conformity to ASTM standard and meets the following specification.
ATDM guaranty the quality of blown bitumen 105/15 with arrangement of international inspector to check quality and quantity of the bitumen on each shipment during the loading to vessel and controlling the production by QC team via batch test report before shipping. ATDM guaranty the quality to meet with ASTM/EN 13304:2009.
Bitumen 105/15 | Specification | Test method astm/en13304 |
Specific gravity @ 25/25 cg | 1.01/1.06 | D-70 |
Penetration @ 25 c | 10/20 | D-5 |
Softening point c | 100/110 | D-36 |
Loss on heating(wt) % | 0.2 max | D-6 |
Flash point c | 250 min | D-92 |
Solubility is cs2(wt) % | 99.5 max | D-4 |
Spot test | Negative | A.a.s.h. |
Oxidized bitumen 105/35 is semi solid oxidised grade of pure petroleum bitumen categorized in polycyclic aromatic hydrocarbons is normally used for different purposes in the construction business.
Oxidised asphalt 105/35 uses in the chemical, fuel, paints, lacquers, varnishes, paper-pulp-board, textile processing, road construction, pavement ,crack seal and repairmen, civil works, roofing,
construction industries; sealing and insulating buildings, adhesive, construction materials additive, dust-binding, coating, insulating and impregnating agent, make rubber and plastic products. The blown asphalt 105/35 products are for paving, roofing; also used in asphalt based paints for corrosion protection of metals, in lining public works structures, adhesives in electrical laminates, base for synthetic turf; typical uses for oxidized asphalt 105/35 include roofing, pipe coating, Portland cement pavement, hydraulic applications, paint manufacturing.
The ATDM is manufacturer of blown asphalt 105/35 in various packing including kraft bag, meltable plastic bag, drum and bulk blown asphalt 105/35 from penetration grade bitumen, which is blown by hot air in a controlled process until the desired specification is reached. The ATDM oxidised bitumen 105/35 can be supplied in any grade and are designated by two numbers to indicate the softening point and penetration ranges. The oxidized asphalt grade 105/35 means softening point is 105°c and penetration is 35 desimillimiter is produced in compliance and conformity to ASTM standard and meets the following specification.
ATDM guaranty the quality of blown bitumen 105/35 with arrangement of international inspector to check quality and quantity of the bitumen on each shipment during the loading to vessel and controlling the production by QC team via batch test report before shipping. ATDM guaranty the quality to meet with ASTM/EN 13304:2009.
Analysis of bitumen 105/35
Bitumen 105/35 | Specification | Test method astm/en13304 |
Specific gravity @ 25/25 cg | 1.01/1.06 | D-70 |
Penetration @ 25 c | 30/40 | D-5 |
Softening point c | 100/110 | D-36 |
Loss on heating(wt) % | 0.2 max | D-6 |
Flash point c | 250 min | D-92 |
Solubility is cs2(wt) % | 99.5 max | D-4 |
Spot test | Negative | A.a.s.h.o.t102 |
Oxidized bitumen 115/25 is most consumable blown asphalt which is semi solid oxidised grade of pure petroleum bitumen categorized in polycyclic aromatic hydrocarbons is normally used for different purposes in the construction business.
Oxidized asphalt 115/25 uses in the chemical, fuel, paints, lacquers, varnishes, paper-pulp-board, textile processing, road construction, pavement ,crack seal and repairmen, civil works, roofing, construction industries; sealing and insulating buildings, adhesive, construction materials additive, dust-binding, coating, insulating and impregnating agent, make rubber and plastic products. The oxidized asphalt 115/25 products are for paving, roofing; also used in asphalt based paints for corrosion protection of metals, in lining public works structures, adhesives in electrical laminates, base for synthetic turf; typical uses for oxidized asphalt 115/25 include roofing, pipe coating, portland cement pavement, hydraulic applications, paint manufacturing.
The ATDM is manufacturer of blown asphalt 115/25 in various packing including kraft bag, meltable plastic bag, drum and bulk blown asphalt 115/25 from penetration grade bitumen, which is blown by hot air in a controlled process until the desired specification is reached. The ATDM blown asphalt 115/25 can be supplied in any grade and are designated by two numbers to indicate the softening point and penetration ranges. The oxidized asphalt grade 115/25 means softening point is 115°c and penetration is 25 desimillimiter is produced in compliance and conformity to ASTM standard and meets the following specification.
ATDM guaranty the quality of blown bitumen 115/25 with arrangement of international inspector to check quality and quantity of the bitumen on each shipment during the loading to vessel and controlling the production by qc team via batch test report before shipping. ATDM guaranty the quality to meet to ASTM/EN 13304:2009.
Bitumen 115/25 | Specification | Test method ASTM/EN13304 |
Specific gravity @ 25/25 cg | 1.01/1.06 | D-70 |
Penetration @ 25 c | 20/30 | D-5 |
Softening point c | 110/120 | D-36 |
Loss on heating(wt) % | 0.2 Max | D-6 |
Flash point c | 250 min | D-92 |
Solubility is CS2(wt) % | 99.5 Max | D-4 |
Spot test | negative | A.A.S.H.O.T102 |
Oxidized bitumen 150/5 is semi solid oxidised grade of pure petroleum bitumen categorized in polycyclic aromatic hydrocarbons is normally used for different purposes in the construction business.
Oxidised asphalt 150/5 uses in the chemical, fuel, paints, lacquers, varnishes, paper-pulp-board, textile processing, road construction, pavement ,crack seal and repairmen, civil works, roofing, construction industries; sealing and insulating buildings, adhesive, construction materials additive, dust-binding, coating, insulating and impregnating agent, make rubber and plastic products. The blown asphalt 150/5 products are for paving, roofing; also used in asphalt based paints for corrosion protection of metals, in lining public works structures, adhesives in electrical laminates, base for synthetic turf; typical uses for oxidized asphalt 150/5 include roofing, pipe coating, Portland cement pavement, hydraulic applications, paint manufacturing.
The ATDM is manufacturer of blown asphalt 150/5 in various packing including kraft bag, meltable plastic bag, drum and bulk blown asphalt 150/5 from penetration grade bitumen, which is blown by hot air in a controlled process until the desired specification is reached. The ATDM oxidised bitumen 150/5 can be supplied in any grade and are designated by two numbers to indicate the softening point and penetration ranges. The oxidized asphalt grade 150/5 means softening point is 150°c and penetration is 15 desimillimiter is produced in compliance and conformity to ASTM standard and meets the following specification.
ATDM guaranty the quality of blown bitumen 150/5 with arrangement of international inspector to check quality and quantity of the bitumen on each shipment during the loading to vessel and controlling the production by QC team via batch test report before shipping. ATDM guaranty the quality to meet with ASTM/EN 13304:2009.
Bitumen 150/5 | Specification | Test method ASTM/EN13304 |
Specific gravity @ 25/25 cg | 1.01/1.06 | D-70 |
Penetration @ 25 c | 1/10 | D-5 |
Softening point c | 145/155 | D-36 |
Loss on heating(wt) % | 0.2 Max | D-6 |
Flash point c | 250 min | D-92 |
Solubility is CS2(wt) % | 99.5 Max | D-4 |
Spot test | negative | A.A.S.H.O.T102 |
